Description
IGS-1050A is a unmanaged gigabit Ethernet switch with 5x 10/100/1000Base-T(X) ports. IGS-1050A supports redundant power inputs, rigid IP-30 housing and have DIP switch for enabling or disabling relay output alarm. In addition, the wide operating temperature range from -40 to 70°C can satisfy most of operating environment.
Features
- 5x 10/100/1000Base-T(X) ports
- Support Jumbo Frame up to 9K Bytes
- Hardware DIP switch to enable/disable warning function
- Rigid IP-30 slim type housing design
- DIN-Rail and wall mounting enabled
- Relay output to carry capacity of 1A at 24 VDC
Industrial Slim Type 5-Port Unmanaged Gigabit Ethernet Switch
Physical ports |
|---|
| 10/100/1000Base-T(X) ports in RJ45 | 5 |
LED Indicators |
|---|
| Power Indicator (Power) | Green: Power LED x 2 |
| Fault Indicator (Fault) | Amber: Indicate PWR1 or PWR2 failure |
| 10/100/1000Base-T(X) RJ45 port indicator | Green for Link/Act indicator.
Lower LED for speed indicator: Amber for 100Mbps, Off-light for 1G and 10Mbps |
Power |
|---|
| Power consumption (Typ.) | 5.5 Watts |
| PoE Output Power | N/A |
| Redundant Input power | Dual 12~48VDC on 6-pin terminal block |
| Overload current protection | Present |
| Reverse polarity protection | Present |
Physical Characteristic |
|---|
| Enclosure | IP-30 Metal |
| Dimensions (mm) | 26.1 (W) x 94.9 (D) x 144.3 (H)mm, 1.03 (W) x 3.74 (D) x 5.68 (H) inch |
| Weight (g) | 420 g |
Technology |
|---|
| Ethernet Standards | IEEE 802.3 for 10Base-T
IEEE 802.3u for 100Base-TX
IEEE 802.3ab for 1000Base-T
IEEE 802.3x for Flow control |
| MAC Table | 1024 |
| Packet buffer Size | 1M bits |
| Processing | Store-and-Forward |
| Switch Properties | Switching latency: 7 µs
Switching bandwidth: 10Gbps
Throughput (packet per second) : 7.24Mpps@64Bytes packet |
| Jumbo frame | 10240 bytes |
Regulatory Approvals |
|---|
| EMC | CE EMC (EN 55035, EN 55032), FCC Part 15B |
| EMI | EN 55032, CISPR32, EN 61000-3-2, EN 61000-3-3, FCC Part 15 B class A |
| EMS | EN 55035 (IEC/EN 61000-4-2(ESD), IEC/EN 61000-4-3(RS), IEC/EN 61000-4-4(EFT), IEC/EN 61000-4-5(Surge), IEC/EN 61000-4-6(CS), IEC/EN 61000-4-8(PFMF) |
| Shock | IEC 60068-2-27 |
| Free Fall | IEC 60068-2-31 |
| Vibration | IEC 60068-2-6 |
| Safety | EN 62368-1 |
| MTBF | 1,867,818 hrs |
Dimensions |
|---|
 |
